D.C. POWER SUPPLY

E.M.M.S. Electrical Machines Modular System 0,3 kW
D.C. Power Supply Module MOD.3004

Mod.3004D with digital instruments

MOD.3004 - DC power supply
It is used for electrical supply of DC 0,3kW EMMS machines.
Excitation voltage and magnetic brake supply are also included.
- Power requirements: 380/415V 3-phase + PE;
- General protection with high sensitivity magneto thermal differential (0,03A)
automatic circuit breaker.
- Mushroom emergency push-button;
- Key consent for all outputs
- All outputs are protected by means of automatic magneto thermal circuit breaker.
- Analog or digital instruments

OUTPUTS:
DC variable output 0-220V, 1,2A for the excitations.
- protection with magneto thermal automatic circuit breaker for DC.
- with 1 x D.C. voltmeter;
- with 1 x D.C. ammeter;

D.C. fixed output: 230V D.C. 3A for the armatures.
- protection with magneto thermal automatic circuit breaker for DC.
- with 1 x D.C. voltmeter;
- with 1 x D.C. ammeter;

- 1 service single-phase safety universal socket 10/16A.

Dimensions: LxWxH: 50 x 35 x 35cm; Weight: 18kg;

-All power supply (standard models):

Code	3-Phase Variable	1-Phase Variabile	DC Variable	1-Phase Fix	DC Fix
Mod.0000	0-48V - 10A	0-48V - 10A	0-36V - 2A	24V - 10A	36V - 4A
Mod.3000	0-420V - 2A	0-240V - 2A	0-230V - 1A	230V - 16A	220V - 3A
Mod.4000	0-420V - 3A	0-240V - 4A	0-230V -1,2A	230V -16A	220V - 5A
Mod.5000	0-420V - 5A	0-240V - 8A	0-230V - 2A	230V - 16A	220V - 5A
Mod.6000	0-450V - 8A	0-240V - 10A	0-230V - 2A	230V - 16A	220V - 10A
Mod.7000	0-450V - 10A	0-240V - 13A	0-240V - 3A	230V - 25A	220V - 15A
Mod.8000	0-450V - 13A	0-250V - 16A	0-240V - 5A	230V - 25A	220V - 20A
Mod.9000	0-450V - 20A	0-250V - 25A	0-240V - 8A	230V - 25A	220V - 20A

In addition to standard solutions, other desk can be realized on request.
